AXON SYSTEMS

AXON Systems GmbH is one of the leading manufacturers of telemetry systems for the contactless transmission of sensor signals. The focus is on the application of strain gauges and temperature sensors. Robust design in the smallest space allows professional measurements under the toughest conditions.

Convincing arguments

for your applications
01//

Plug & Play

Install applied measuring shafts, Start measurement. Ring stator for the simplest system setup Cross-compatibility of the components within the system family

02//

Robust

for temperatures from -40 ° C to + 140 °C reliable transmission even in water or oil and environment with high EMC load, CE certified.

03//

Smart

Three rotor variants (chip rotor, flex rotor and head rotor) for optimum utilization of the installation space.

04//

Flexible

All motor variants with battery or inductive supply Simultaneous non-contact transmission of the measured data Ring stator or pick-up stator depending on the installation space situation.

05//

Integration

Distances between rotor / stator up to 70 mm. Metallic environment without influence on the transmission quality
Alternative: Pick-up induction head for large diameter shafts.

06//

Availability

Delivery time of the hardware usually
5 days from order. Delivery for applied and calibrated measuring shafts and flanges within 10 days.

FEATURED PRODUCTS

Telemetry systems for strain gauge and temperature measurements
Axon Systems J1 telemetry system for for contactless transmission of strain gauge signals with analog transmission

J1

High-precision 1-channel telemetry system for wireless transmission of strain gauge signals. (WTSGS)

- robust
- reliable
- Operating temperatures up to + 140 ° C
- inductive power supply
- high measuring accuracy
- easy installation

J1DB

1 channel telemetry system for strain gauge measurements with additional monitoring of the rotor voltage supply

- robust
- reliable
- Operating temperatures up to + 140 ° C
- inductive power supply
- high measuring accuracy
- easy installation

J8T

High precision 8-channel digital telemetry system for simultaneous transmission of 8 thermocouple signals.

- robust
- reliable
- Operating temperatures up to + 140 ° C
- inductive power supply
- high measuring accuracy
- easy installation

"Customized solutions"

Our experienced team of engineers and technicians will assist you in planning your individual application.



Contact us...
